Antenna Accessory LNB Head for Satellite Dish

Triax TSI 100 Gold Universal Single LNB Satellite Receiver Head

TRI-118-999
Triax TSI 100 Gold Universal Single LNB Satellite Receiver Head
Triax TSI 100 Gold Universal Single LNB Satellite Receiver HeadTriax TSI 100 Gold Universal Single LNB Satellite Receiver HeadTriax TSI 100 Gold Universal Single LNB Satellite Receiver Head
Triax TSI 100 Gold Universal Single LNB Satellite Receiver Head

Key features of Triax TSI 100 Gold Universal Single LNB Satellite Receiver Head

• Impedance: 75 Ω
• Input frequency lower band: 10.7-11.7 GHz
• Input frequency high band: 11.7-12.75 GHz
• Output frequency low band: 950-2150 MHz
• DC current consumption: 80 mA
• Dimensions: 95 mm x 64 mm x 57 mm
• Net weight: 0,076 kg
• Manufacturer's article number: 304871
• One indoor satellite receiver unit can be connected

The product is on stock. (1-4 piece(s))
Gross price (including 27% VAT): 4.53€ (Net price: 3.57€)
Add to Cart Price Watch
You can ask for e-mail price notifications when the price of this product gets under a limit you specify. To use this feature you need to have a user account and to be signed in.
1 year(s) warranty Based on product sizes and weight, considering the minimal order quantity, this product is eligible for delivery to GLS parcel machines in Hungary.
tsi_100_gold_304871-single_LNB_Data.pdf
English prospectus

1 year(s) warranty Based on product sizes and weight, considering the minimal order quantity, this product is eligible for delivery to GLS parcel machines in Hungary.

Further details of Triax TSI 100 Gold Universal Single LNB Satellite Receiver Head

• Operating voltage vertical: 10.5-14.5 V/DC
• Operating voltage horizontal: 15.5-21.0 V/DC
• VSWR output: 2.0:1
• Reflector type: offset
• LO frequency low band: 9,75 GHz
• LO frequency high band: 10.6 GHz
• Smoothness gain (in the 26 MHz segment)5 dB
• Conversion gain (typical): 57...65 dB
• Noise figure max: 0,3 dB
• Cross polarization isolation: 23 dB
• Colour: RAL 9002 - Grey white
• LO temperature drifting: ± 3 MHz
• Phase noise room temperature: 1 kHz- 65 dBc/Hz
• Phase noise room temperature: 10 kHz- 83 dBc/Hz
• Phase noise room temperature: 100 kHz- 95 dBc/Hz
• Image rejection (min): 40 dB
• Great quality, low footprint
• Cutting edge RF technology
• Excellent cross-pole isolation
• Excellent low noise / low phase noise
• High performance / low power consumption
• Weatherproof and suitable for harsh environments
